BM-R4
Gamut Lighting Beam R4 is a small luminaire developed to brighten the night, outdoor garden and outdoor building facade using the high performance of COB light source.
Technical data
Print technical data
- IP67
| INSTALLATION | Surface mounted (Ceiling, Wall, Floor) |
|---|---|
| LIGHT SOURCE | LED |
| LED QUANTITY | 12 Nos |
| MOUNTING | Surface mounted ( Ceiling, Wall, Floor) |
| LED COLOR | 2200/2700/3000/4000/5000/RED/GREEN/BLUE |
| IP RATING | IP67 |
| RATED POWER | 1W / 2W |
| BEAM ANGLE | 8°, 23°, 43°, 10°x41° |
|---|---|
| BODY MATERIAL | Anodized aluminium body and bracket tempered glass diffuser |
| BODY FINISH | Anodized Aluminum (A), Black (B), Custom (X) |
| LAMP LIFE | 50,000 Hrs |
| CONNECTION | Parallel (supply “P”) |
| WIRING | Provided with 150cm neoprene cable |
| SUPPLY VOLTAGE | 24V DC / 230VAC |
| OPTIONS |
Diffuser : Tempered Glass |
Read more
Close
Accessories and power supply units
Accessories (0)
No Accessories associated with this product
Power supply units (0)
No Power Supply Units associated with this product
Control gear (0)
No Control Gears associated with this product
Versions
BM-R1
Rated Power : 1W / 2W
Supply Voltage : 24V DC / 230VAC
Mounting : Surface mounted ( Ceiling, Wall, Floor)
BM-R2
Rated Power : 1W / 2W
Supply Voltage : 24V DC / 230VAC
Mounting : Surface mounted ( Ceiling, Wall, Floor)
BM-R3
Rated Power : 1W / 2W
Supply Voltage : 24V DC / 230V AC
Mounting : Surface mounted ( Ceiling, Wall, Floor)
