ART R
Gamut lighting Art R is using as surface mounted wall luminaire developed to brighten the night and outdoor building facade. The cylinder shape of the luminaire is slim and compact up and down lighting.
Technical data
Print technical data
- IP65
| INSTALLATION | Wall mounted |
|---|---|
| LIGHT SOURCE | LED |
| MOUNTING | Surface Mounted (Wall) |
| LED COLOR | 2700/3000/4000/6000 K, (UNIQUE COLORS: RED, GREEN, BLUE, WHITE) |
| IP RATING | IP65 |
| DELIVERED LUMEN |
490 lm/Window |
| RATED POWER | 5 W |
| BEAM ANGLE | 6° |
|---|---|
| BODY MATERIAL | Heavy duty die cast aluminium |
| BODY FINISH | Black |
| LAMP LIFE | 50,000 Hrs |
| CONNECTION | Parallel (supply “P”) |
| DIMENSIONS | Ø108 X 70mm, Ø95 X 52mm |
| WIRING | Junction in supply box |
| SUPPLY VOLTAGE | 24V DC. 48V DC, 100-240V AC(43-60Hz) |
| DRIVER / POWER SUPPLY DETAILS |
ON/OFF DALI AN - 1-10V DMX |
| DIMMING | NON-DIMMABLE, DALI, 1-10V, DMX |
| COLORS | WHITE/BLACK/GREY |
| NOTES |
LED Module : High power LEDs on metal core PCB; Collimating lens made of optical polymer/pmma |
| LENS OPTIONS |
PMMA Diffuser |
| OPTIONS |
Electrical Protection : EMC; Inrush current Direction : 4; 3; 2c; 2i; 1 |
