FO

Gamut Fokal is a recessed wall luminaire developed to brighten the floor using the high performance of the LED light sources. The outdoor lighting fixture is designed with a simple square shape with the point frame in the centre to complete the unique and contemporary look. The special feature of lighting design is to make the eyes comfortable and minimize the dark zone area from the wall. It is specially designed to create a beautiful shape of the light pattern on the floor.

Technical data

Print technical data
  • complies with the European standard
  • IP67
INSTALLATION Wall Recessed
LIGHT SOURCE LED
MOUNTING Wall Recessed
LED COLOR 2700/3000/4000/5000K
IP RATING IP67
DELIVERED LUMEN 408lm @ 7W
542lm @ 11W
886lm @ 18W
1427lm @ 29W
RATED POWER 7/11/18/29 W
BEAM ANGLE 120°
BODY MATERIAL Heavy duty die-cast aluminum
BODY FINISH Black, White, Grey
LAMP LIFE 50,000 Hrs
CONNECTION Parallel Connection
WIRING Provided with 30cm PVC cable
SUPPLY VOLTAGE 100-277V AC
CRI 80+
